Food-Grade Silicone Sheets (where certified)
High-purity white, translucent, and blue food-grade silicone sheeting manufactured in controlled hygienic environments. Non-toxic, non-marking, and completely free of plasticizers, heavy metals, or harmful volatile organic compounds.
Types & Configurations of Food-Grade Silicone Sheets (where certified)
White FDA Compliant Silicone Sheeting
Classic food-grade sheet widely used for dairy, bakery, and confectionery gasket stamping.
Metal & X-Ray Detectable Blue Sheeting
Engineered silicone compound detected by food processing safety scanners if fragment breaks.
Translucent Platinum-Cured Food Sheeting
Ultra-clean sheeting with zero peroxide residue for high-purity wine and beverage lines.
Fabric-Reinforced Food Gasket Sheeting
FDA approved polyester cloth insertion for high-pressure sanitary pump flanges.
Textured Non-Stick Food Conveyor Sheets
Embossed surface silicone sheeting conveying sticky candy, dough, and chocolates.
Key Industrial Applications
Specifications & Technical Details
Food-Grade Silicone Sheets (where certified) can be precision-manufactured in custom dimensions, wall thicknesses, cross-sections, and durometers to match your exact application specifications. Below are typical engineering cross-section drawings and technical parameters for reference.
Typical Dimension Drawings & Blueprint Cross-Sections
Technical Specifications
| Parameter | Specification / Options |
|---|---|
| Sanitary Approvals | Complies with FDA 21 CFR 177.2600, BfR Recommendation XV, and EC 1935/2004 |
| Thickness Range | 0.5mm up to 20.0mm |
| Roll Widths | 1000mm, 1200mm, 1500mm standard widths |
| Hardness Options | 40A, 50A, 60A, 70A Shore A |
| Chemical Resistance | Withstands Clean-in-Place (CIP) caustic and acid wash cycles up to 90°C |
| Color Availability | FDA White, Optically Clear Translucent, Metal-Detectable Cobalt Blue |
| Operating Temp | -60°C to +200°C (steam sterilizable up to +135°C) |
Material Selection & Properties
We offer specialized compound formulations tailored to chemical media, thermal extremes, static deflection, and dynamic fatigue requirements. The best material depends on your operating environment and required service life.
| Material / Polymer | Key Engineering Properties | Recommended Applications & Considerations |
|---|---|---|
| General Purpose Silicone | Thermal stability from -60°C to +200°C, dielectric | Electrical insulation, high-temp oven door seals |
| Platinum-Cured Silicone | Ultra-pure, non-yellowing, zero peroxide byproducts | Medical fluid transfer, pharmaceutical filling lines |
| High-Temperature Grade | Continuous operation up to +250°C, intermittent +300°C | Automotive turbocharger hoses, furnace baffles |
| Flame Retardant (UL94 V-0) | Low smoke toxicity, self-extinguishing flame resistance | Rail transit interior seals, EV battery pack insulation |
| Conductive / Antistatic Silicone | Volume resistivity 10² to 10⁴ Ω·cm for ESD shielding | Avionics EMI/RFI shielding, semiconductor handling |
Important Engineering Guidance
The above properties are general characteristics. Final material selection depends on your specific application, operating conditions, load requirements, media compatibility, and service temperature. Please contact our polymer engineering team for tailored compounding guidance on Food-Grade Silicone Sheets (where certified).
Production Batch Gallery
Actual production batch examples of Food-Grade Silicone Sheets (where certified) manufactured for OEM, automotive, railway, and heavy engineering clients. We manufacture standard catalogue sizes as well as bespoke custom geometries from your CAD models or physical samples.
Request an Engineering Quote
Share your required dimensions, polymer grade, or 2D/3D drawings for immediate engineering review and quote.
